Koyker 2785 PRO Loader
| Make | Koyker |
| Model | 2785 PRO Loader |
| Type | Pro Loaders |
Your Preferred Location
Description
With Pro Loaders you are able to roll back larger loads with superior lift capacity and heights. The soft ride nitrogen accumulator (optional feature) is easy-riding, making it easier on the mount, the loader, the tractor and YOU!
- Mechanical Self-Leveling
- Euro Attachment System
- Uni-Seal Pistons
- Greaseless
- Increased Roll Back Angle & Force
- Soft Ride Nitrogen Accumulator
Models
Specification
| Description of Equipment Rated | |
| 3.1 Loader Model | Koyker Pro 2785 |
| 3.1.1.1 Bucket Width | 8' |
| 3.1.1.6 Capacity | 36 ft |
| 3.3.1 Rated Flow | 25 GPM |
| 3.3.2 Maximum Pressure | 2900 PSI |
| Lift Cylinder Dia. (Inches) | 3 1/2 |
| Attachment Cylinder Dia. (Inches) | 3 1/4 |
| Tractor HP Range | 180 - 280 |
| Dimensional Specifications | |
| 4.1.4 (A) Lift Height | 15' 6" |
| 4.1.2 (B) Lift Height Under Level Bucket | 14' 6" |
| 4.1.3 (C) Clearance with Bucket Dumped | 12' 2" |
| 4.1.5 (E) Max Dump Angle | 50° |
| 4.1.7 (G) Max Rollback Angle | 42° |
| 4.1.8 (H) Digging Depth | 6" |
| 4.1.9 (J) Overall Height in Carry Position | 7' 8" |
| Operational Specifications | |
| 5.1.1 (U) Lift Capacity at Max Height at Pivot Pin | 6060 lbs |
| 5.1.2 (V) Lift Capacity at Max Height (31.5) | 4315 lbs |
| 5.1.3 (W) Lift Capacity at 59" Height at Pivot Pin | 7195 lbs |
| 5.1.4 (X) Lift Capacity at 59" Height (31.5) | 5770 lbs |
| 5.1.5 (Y) Break Out Force at Pivot Pin | 8670 lbs |
| 5.1.6 (Z) Break Out Force | 6675 lbs |
| 5.1.10 Raise Time (seconds) | 5.8 |
| 5.1.11 Lowering Time (seconds) | 3.9 |
| 5.1.12 Bucket Dumping Time (seconds) | 3.8 |
| 5.1.13 Bucket Rollback Time (seconds) | 2.7 Description of Equipment Rated |
